Avant 630

Description

• Avant 600 series is the real all-rounder in the range. It combines power, lift capacity and professional hydraulics which are in a very compact package. This makes 600 series a very popular machine for many professionals in landscaping, groundcare, construction, farming, horse stables, and many other customers. The max. 1,1-tonne lift capacity is just perfect for a multitude of jobs and the powerful auxiliary hydraulics runs almost all Avant attachments. The customers also like the easy transporting of 600 series. Thanks to the compact dimensions it is possible to fit both the loader and the attachments on the trailer.

Technical Information

Standard wheels        -           26 x 12.00 - 12" TR/GR

Transmission               -           Hydrostatic, Avant Optidrive®

Width                         -           1290 mm

Length                         -           2570 mm

Height                         -           2035 mm

Telescope length        -           600 mm

Weight                        -           1500 kg

Pulling force max.      -           1200 kp

Drive speed                -           14 km/h

Auxiliary hydraulics, oil flow max. / Auxiliary hydraulics, pressure max.    -           44 / 200

Lift Height                   -           2835 mm

Lift Capacity                -           1100 kg

Engine make and type           -           Kohler KDI-TCR 1903, Stage V

Engine output             -           26.8 hp

Engine power standard         -           ECE R120

Maximum torque       -           72 Nm

Maximum torque       -           2200 rpm

Fuel                             -           Diesel

Engine output            -           19 kW

Turning radius inside/outside           -           900 mm / 2190 mm

Weight ROPS / GT      -           1500 kg / 1650 kg
